Date: 11 August 2020
Pick your poison. It can be deadly for good reasons such as protecting crops from harmful insects or fighting parasite infection as medicine—or for evil as a weapon for bioterrorism. Or, in extremely diluted amounts, it can be used to enhance beauty.
Simply put, “a poison is something that acutely degrades your health, or your health state,” said Andrey Kovalevsky, a crystallographer and biochemist at ORNL. He is an expert in atomic-level understanding of enzyme function, drug binding and drug resistance. Using neutrons and X-rays, he studies how enzymes work in the body and, depending on the specifics, how to inhibit or reactivate them using small organic molecules.
“Depending on the poison and amount, the effect can be very quick—within seconds—or it can be slow,” he added. The body triggers its own defenses to counteract a poisonous substance; however, it’s usually not enough. Any level of exposure could be deadly, especially if the type of poison is not immediately known to a first responder or medical team attending to an affected patient.
An antidote must act fast—before the poison does irreversible damage—to be effective and save lives.
Mirror the poison
Kovalevsky is part of a team, led by Zoran Radić of the University of California, San Diego’s Skaggs School of Pharmacy and Pharmaceutical Sciences, developing a new family of antidotes for poisons called organophosphates, which include nerve agents. Radić’s research uniquely targets the root cause of organophosphate poisoning, going beyond just treating the symptoms as with existing remedies.
Their focus is on the complex biochemical mechanisms that control and maintain the body’s nervous system. They start with acetylcholine, or ACh, which is a compound found at the junction of muscles and nerves and also in the brain. ACh functions as a neurotransmitter that maintains normal communication between nerves and muscles. But ACh doesn’t act alone.
The enzyme called acetylcholinesterase, or AChE, is also where muscles and nerves meet. Its job is to provide specific control of the levels of ACh compound by degrading it, which ensures the nerves are functioning properly.
When a person is exposed to a nerve agent, or to copious amounts of an insect spray, for instance, the poison passes quickly from the lungs or skin into the blood stream and races to the nervous system. As it reaches the muscle-nerve junctions, the poison overwhelms and inhibits the work of the AChE enzyme.
As the AChE enzyme is under attack and unable to degrade ACh, the levels of the ACh compound rise, disrupting the balance between muscles and nerves. This wreaks havoc on the body.
“Instead of being too little of something, there’s too much of this neurotransmitter. So, the nerves’ receptors are overexcited, and people can go into shock, have tremors and seizures and start sweating because their glands are working too much,” Kovalevsky explained. In the end, the affected person will likely die because they stopped breathing.
Radić said the antidote must mirror the poison’s activity without acting as an inhibitor, too.
“These poisons, typically comprised of uncharged or neutral molecules, traverse biological membranes very quickly into the blood and are then distributed from blood to tissue, including the central nervous system. And all of this happens in minutes after exposure,” he said.
If done right, the antidote will relieve the AChE enzyme of the poison’s attack, essentially excising the poison’s molecule attached to the enzyme, and allowing it to begin leveling out the ACh neurotransmitters and ultimately calm down the entire nervous system. The trick is to ensure the antidote is designed not to overstay or get too attached to the enzyme—and become part of the problem.
To the rescue
In a study funded by the CounterACT Program, National Institutes of Health Office of the Director and the National Institute of Neurological Disorders and Stroke and published in the Journal of Biological Chemistry, Radić’s team designed and tested fast-acting drugs called reactivators on three different nerve agents and one pesticide with positive initial results.
For this study, the team used X-ray crystallographic analysis to look at the RS194B complex with the AChE enzyme alone and then introduced an analog of a chemical nerve agent called VX—one of the deadliest chemicals ever made. While RS194B didn’t bind as expected, the experiment did foster ideas on how to redesign “a sort of elite compound,” Kovalevsky said.
After some tweaks to the drug design, the team came up with a new paradigm that can completely change how researchers think about a reactivator design. They ran computer simulations and later synthesized several most promising compounds of the altered design options, which provided details on their properties and clues on how each compound might work.
They analyzed the impact of each drug design variation, plus the original RS194B, with nerve agents Sarin, Cyclosarin, VX and a pesticide Paraoxon. Also, the team included 2PAM (also called Pralidoxime)—the only antidote for organophosphate poisoning that is approved by the U.S. Federal Drug Administration for use in adults and children—which served as a control for the experiments.
Based on the study’s initial results, several of the team’s drug design variations worked better than RS194B and 2PAM, which Kovalevsky said is a very encouraging result for their novel reactivator design ideas.
“One of distinctions of our antidote is that they can engage different organophosphate poisons more effectively, because their reactivation structures can change with their protonation,” Radić said. “Unlike X-rays, diffraction of neutrons is an experimental technique that can tell us about the position of protons in both the antidote and in the poisoned enzyme.”
Big, tiny crystals
To get a better picture of the novel reactivator design, the team used neutron crystallography at ORNL’s High Flux Isotope Reactor, a Department of Energy Office of Science user facility. Kovalevsky operates the instrument named IMAGINE, which uses neutron diffraction techniques to look at the structure of a single crystal at atomic scale.
The molecular structure of the protein is complex, which requires growing large single crystals—a strength of ORNL’s—for neutron diffraction. Neutrons are highly sensitive to light elements such as hydrogen, and they are particularly well suited to find individual hydrogen atoms in protein crystals that X-rays cannot detect. The data collected from IMAGINE, along with information from a neutron experiment performed at Institut Laue–Langevin in France, confirmed it’s possible to pinpoint the location and distribution of each hydrogen atom in the protein.
The team will continue growing larger crystals for analysis, which should produce higher resolution datasets and inform adjustments to the promising, novel drug designs. Their continued research could ultimately confirm a new class of fast-acting, life-saving antidotes for organophosphate poisoning.
